Aqua La Diva | CD Transport | Audio Emotion
Aqua La Diva | CD Transport | Audio Emotion
Aqua La Diva | CD Transport | Audio Emotion
Aqua La Diva | CD Transport | Audio Emotion

Product Description

Uncompromised in every respect, La Diva M2 CD Transport is the culmination of aquas R&D in the areas of electronic and mechanical engineering.

Features

  • High performance proprietary ISDC (Isolated Synchronous Discrete Circuit) digital decoding and clock manager
  • Custom designed discrete circuit with high-speed photocouplers for Galvanic and magnetic isolation between CD drive unit and digital output
  • Ultra massive chassis construction and newly developed high-rigidity sub chassis with Nextel for CD drive unit cancels internal and external acoustic and mechanical vibrations, enabling exceptionally accurate "Red Book" RF signal
  • DC disc drive motor allows to read the data accurately and minimise Jitter
  • Moplen clamp to avoid flywheel masses and vibrations
  • Sophisticated signal processing technology assures excellent CD Red Book signal
  • High-performance multi-stage voltage regulator (high-current stage for accurate servo DISC drive rotation, tracking and focus)
  • Jitter free digital interface AQlink (I2S protocol), uncompromising digital connection to Aqua DACs
  • etherCON RJ45 (AQlink) output connection to DAC, employs CAT6 cable can connect both RJ45 and professional etherCON RJ45
  • Separate custom-built toroidal transformers for digital and servo motors/actuators
  • MODULAR DESIGN with upgradeable multi board system
  • Precision Philips CD-Pro2 transport customised
  • High-quality parts selected for sound quality:
    • 105° long life capacitors
    • low noise Metal Foil ultra-precision resistors
    • metallised film pulse capacitor
    • ultra-fast diodes
    • halogen free cables
  • Aluminium top loading tray machined from billet
  • Non-magnetic low-resonance aluminium chassis with Nextel
  • Field upgradeable firmware
  • OLED display with user off-selectable illumination
  • Designed and handmade in Italy
  • Output
    • etherCON RJ45 - AQlink (I2S serial bus)
    • XLR AES/EBU
    • BNC coax (S/PDIF)
    • RCA coax (S/PDIF)
    • ST fiber (AT&T)
    • BNC word clock
  • 5-year warranty

For the Full Technical Specifications click here.

Output:

  • - EtherCON RJ45 - AQlink (I2S serial bus)
  • - XLR AES/EBU
  • - BNC coax (S/PDIF)
  • - RCA coax (S/PDIF)
  • - ST fiber (AT&T)
  • - BNC word clock

Disc Compatibility

CD, CD-R
CD Formats

Red Book

Drive mechanism

PHILIPS CD-PRO2 Customized
Pick-Up Technology

TRIGINTA preamplifier & Laser supply
Optical

Single focault - 3 beam method
Disc Drive Motor

Precision DC Motor
Servo power supply

High-performance voltage regulator (high-current)
Digital decoder

Proprietary ISDC
Digital  isolators

Custom designed discrete circuit with high-speed photocouplers
Digital Output

2 S/PDIF 75 :
- 1 coaxial BNC
- 1 coaxial RCA
1 AES/EBU (XLR) 110
1 AQlink - I2S serial bus
(etherCON RJ45)
1 AT&T (ST Fiber)
Word Clock Output

1 coaxial BNC  75
AQlink (I2S bus)

CMOS level
Native Sample Rate

16 bit / 44.1 KHz
Front Panel

Standby, Display, Play, Pause, Stop, Previous, Next Switches
Display

Fluorescent display (VFD) with user off-selectable illumination
Remote Control

Infra Red (RC5)
Power Consumption

100-115V / 220-240V; 50 or 60Hz - 38VA
Disc loading

Top-Loading (Manual)
Dimensions

( W x D x H ) 450 x 370 x 100 mm
Weight

10 kg
Front finish

Satin Alu Silver
Case finish

Grey Nextel powder coated

Specifications

Product Type
CD Transport
Brand
Aqua Acoustics
Condition
New
Product Code
AQUA-LADIVA
