- Brilliant Condition
- Original Box
- 1.2m Length
All enthusiasts are looking for the same things: Verisimilitude, a sense of engagement promoting suspension of disbelief, a veritable immersion in audio and video experience. To detach without effort from modern time’s exigencies requires meticulous preparation of the entire playback chain, especially cables, power cords and AC distribution.
Evolution II, an update of the extremely well received Evolution series, incorporates newly-engineered anti-resonance cable clamps as well as an upgraded dielectric/insulation of RoHS-compliant Pb-free PVC incorporating anti-resonance carbon particles in its manufacture. Our Pure Transmission philosophy incorporates rhodium-plated pure copper conductors, even the IEC connectors of the Evolution II power cord. No detail too small, every element of signal and power transmission engineered to within an inch of its life, treated with advanced processes, and turned out with beautiful design and build quality to enrich every music experience.
- High performance beautifully engineered gold-plated [FP-701M(G)/FP-702F (G)] XLR connectors
- XLR connector pins beautifully engineered copper alloy α (Alpha)-conductor with PBT dielectric
- XLR body and housing made of nonmagnetic copper alloy
- Shield 1 0.12 mm α (Alpha) conductor wire braid
- Cable insulated with polypropylene reducing capacitance and damping vibration
- Results in greater resolution, clarity, powerful dynamics, and an ultra-quiet soundstage in which music develops more fully without artificial upper-frequency “presence region” glare
- α (Alpha) Conductor Is Composed Of Fine OCC Wire Strands Treated With Furutech’s α (Alpha) Cryogenic and Demagnetizing Process ・
- α (Alpha)-OCC Conductor wires are treated with the FURUTECH α(Alpha) to minimize transmission loss.
- Finished with High Performance FP-701M(G)/702F(G) XLR Connectors.
- The pin of FP-601M(R)/602F(R) is made using non-magnetic 24k Gold Plated Eutectic cast Brass with dielectric PBT. Non-magnetic Brass Housing (Black).
- Shielded with 0.12 mm α(Alpha) conductor wire Braid realizing superior noise isolation.
- Insulated with high quality Polypropylene which contributes to a reduction in capacitance.
Tech spec
Construction:
30-strand a (Alpha)–OCC Conductor·0.18mm, 1.14mm diameter
Insulation:
30% air-foamed HDPE (Red/White) 2.60mm diameter
Cable Lay:
Two twisted cores with cotton yarn
Cable Wrap:
Non-woven fabric wrap ~5.8mm diameter
Shield-1:
0.12mm braided a (Alpha) Conductor·Braid density: 80% UP x 6.3mm diameter
Sheath:
Two layers flexible PVC (Dark Brown) 8.0mm diameter
Shield-2:
Special EMI- and noise-absorbent Formula GC-303 module
Jacket:
Nylon yarn braid. ~10.5mm diameter
Max. Conductor Resistance:
26.4 O/km JISC3005 6 20Ω
Min. Insulation Resistance:
1000 MOΩ km JISC3005 9.1 20Ω
Dielectric Strength :
AC. 500 V/1 min JISC3005 8
Electrostatic Capacitance:
Approx 42 PF/m at 1 KHz
Characteristic Impedance:
Approx 120 O at 100 MHz
