Gato Audio DPA-4004 Multichannel Power Amplifier

Home > Amplification > Power Amplifiers > Gato Audio
Stock code: GATODPA4004


    For more information on any of our products please call us:


    01333 425999


    Our Price: £3,995.00
    • Product Info
    • Stock Check
    • Part Exchange
    • 0% Finance

    Product Information

    The four-channel Gato Audio DPA-4004 is a flexible solution that offers a variety of options and combinations with the number of power output channels. A feature of the amplifier is to use modern technology to build the Class-D output stages , which in combination with a bridge connecting channel enables the production of high output power with a compact and elegant design.


    Real power

    The Gato Audio DPA-4004 provides at least 4x400W under 8 Ohm load, and at 4 ohms the value of channel capacity doubles. Each pair of channels in the amplifier can be connected in a bridge circuit, allowing individually configured power for multi-channel systems, or bi-amping speakers. The most obvious candidate to work in conjunction with the DPA-4004 is the award winning Gato Audio PRD-3 pre amp/dac, but the new model can also accompany the DIA-250/400 integrated amplifier, offering more channels and flexibility in terms of channel capacity. In multichannel systems, the DPA-4004 can serve to enhance the surround sound processor signals, possibly in combination with PRD-DIA-250/400 in the "Home Theater" mode.


    Class-D with true 'analogue' audio

    The DPA-4004 is a technically advanced solution in the form of Class D output stages with a separate power supply. The amplifying part is built on proven technology, with an optimized precision high-frequency generator and PWM modulator. Fast and accurate switching MOS-FET transistors have a very low on-state resistance, providing superior performance at high frequency with a minimal loss. Output filters on quality polypropylene capacitors and coils with low resistance convert powerful PWM signals back into analogue for an immersive detailed and textured sound.


    Specifications:

    Output power (230 VAC) 4x 400W / 2x 800W / 1x 800W 250W + 2x / 2 x 400W @ 8 ohms
    or
    4x 800W / 2x 1600W / 1x 1600W + 2x 800W @ 4 ohms
    Frequency 20 Hz - 20 kHz ± 0.5 dB
    2 Hz - 70 kHz ± 3 dB
    CED (power amplifier) <0.01%
    S / N ratio > 110 dB
    Input resistance 20 kΩ RCA or 40 kΩ (balance).
    Strengthening 26 dB
    Recommended Load Impedance SE 4 -16 Ω, BTL 8 -16 Ω
    Switching
    Balanced analog inputs 2 pairs of gold-plated XLR (Neutrik)
    Unbalanced analog inputs 2 pairs of gold-plated RCA (Stereo)
    Acoustic Outputs 4 pairs of gold-plated terminals (banana)
    Trigger 12 1 mini jack
    Dimensions and Power
    Power Requirements 115 VAC / 230 VAC, 50 Hz / 60 Hz
    Power consumption Standby <1W, Idle <75 W,
    Max. <2000 W
    Dimensions (WxHxD) 325 x 105 x 390 mm /12.8 x 4.1 x 15.4 "
    Weight 13kg
