Product Description

The SUB3 is a sub-woofer designed to work with the Chartwell LS3/5 and LS3/5A from Graham Audio, but it is also applicable to other designs of similar sensitivity and impedance. Designed by Derek Hughes, it employs a novel bass loading technique to achieve extension down to 35Hz in a compact enclosure.

They are supplied in pairs, and are designed to be placed near to the rear wall, while the main loudspeakers remain in their usual 'free space' position. Output is via the front-facing reflex port.

There are connections on the rear for the input from the amplifier and output to the main speakers. There is also provision for feet or spikes to be fitted to the base of the cabinet. Being passive, there are no controls to misadjust - the system is designed to be "plug and play".

The crossover uses high quality components, including air-cored inductors for zero saturation distortion and polypropylene capacitors. The system crosses over at 100Hz, and in doing so, relieves the LS3/5 or LS3/5A of energy frequencies below this point. This will allow the system to reach greater replay volumes, providing there are adequate reserves in the amplifier used.

Technical Specifications

Alignment4th order bandpass
FinishReal wood veneer
Dimensions (w/h/d)30cm by 30cm by 34cm
Frequency response35Hz to 100Hz
Nominal impedance8
Sensitivity84dB SPL (2.83V, 1m)
Recommended amplifier power30 to 80 watts unclipped programme
ConnectionsGold-plated binding posts

Manufacturer Site

Specifications

Product Type
Loudspeakers
Speaker Type
Subwoofer
Brand
Graham Audio
Condition
New
Product Code
GRHM-SUB3

Delivery Information

Delivery is free for all orders over £250.

'In Stock' items ordered before 1pm will be dispatched the same day.

We use DPD Local 'Next Day Service' for most UK deliveries. Orders sent via 'DPD Local - Next Day Service' will be fully tracked with a 1-hour delivery timeslot on the day of delivery. Standard delivery is Monday to Friday.

Saturday delivery can be selected at checkout for £19.95.

Small items and LP's may be sent using Royal Mail.

Large/heavy items may be sent using TNT Express.

For all other countries please visit the 'Delivery Information' link in the footer.

Occasionally, due to stock demand, we can sell out. If this occurs when you make a purchase, we will inform you quickly. Most out of stock items are available for dispatch within 3 working days. If your purchase is urgent, please contact us to check availability.
