MOONDROP CHU II DSP In-Ear Monitors
MOONDROP CHU II DSP In-Ear Monitors
Our price match promise...
If you find an identical item cheaper from one of our online competitors, tell us and not only will we match the price, we'll beat it by 10% of the difference.
Estimated Shipping Widget will be displayed here!
The Moondrop Chu II DSP (Chu 2 DSP) combines the high-performance hardware architecture of the Chu II with integrated digital signal processing and USB-C connectivity. Featuring a 10mm dynamic driver fitted with an Aluminium-Magnesium (Al-Mg) alloy dome composite diaphragm, the Chu II DSP delivers extended treble extension, natural resolution, and controlled low-frequency dynamics across all playback scenarios.
Housed in a zinc-alloy acoustic cavity with a precision CNC-machined brass nozzle, the Chu II DSP incorporates hardware-level DSP tuning supported by the Moondrop Link application. Users can toggle between three onboard bass preset profiles directly via the app to suit individual listening preferences. Fitted with a 0.78mm 2-pin detachable USB-C DSP cable, the earphones provide direct digital compatibility with modern smartphones, tablets, and computers without requiring an external DAC or adapter.
KEY FEATURES & PROPRIETARY TECHNOLOGIES
- Aluminium-Magnesium Alloy Dome Diaphragm: Rigid Al-Mg dome extends high-frequency bandwidth and micro-detail, paired with a flexible suspension surround for low-distortion bass response.
- Hardware DSP & Moondrop Link App Integration: Features integrated DSP with three selectable bass tuning presets toggled via the Moondrop Link application.
- Precision CNC Brass Acoustic Nozzle: Separate brass nozzle component provides high density to stabilize acoustic resonance and refine tonal timbre.
- USB-C Digital Cable Interface: Direct USB-C termination provides clean digital decoding without external dongles, featuring built-in inline control and microphone capability.
- Detachable 0.78mm 2-Pin Connection: Universal 2-pin connectors allow for easy cable replacement, custom upgrades, or conversion to Bluetooth ear-hooks.
- Durable Alloy Cast Shell: Rigid zinc-alloy housing finished with a protective anti-corrosion coating for daily durability.
SPECIFICATIONS
| Specification | Detail |
|---|---|
| Product Category | In-Ear Monitor (IEM) / USB-C DSP Dynamic Driver Earphones |
| Brand / Model | Moondrop — Chu II DSP (Chu 2 DSP) |
| Driver Configuration | 10mm High-Performance Dynamic Driver |
| Diaphragm Material | Aluminium-Magnesium (Al-Mg) Alloy Dome Composite Diaphragm |
| Shell / Cavity Material | Cast Zinc Alloy with CNC-Machined Brass Nozzle |
| Digital Signal Processing (DSP) | Built-In Hardware DSP with 3 Selectable Bass Presets (via Moondrop Link App) |
| Frequency Response | 15 Hz – 38,000 Hz |
| Effective Frequency Response | 20 Hz – 20,000 Hz (IEC60318-4, -3dB) |
| Sensitivity | 119 dB/Vrms (@ 1 kHz) |
| Impedance | 18 Ω ± 15% (@ 1 kHz) |
| Total Harmonic Distortion (THD) | ≤ 0.5% (@ 1 kHz, 94 dB) |
| Connector Type | 0.78mm 2-Pin Detachable |
| Plug Termination | USB-C Digital Plug |
| Included Accessories | 0.78mm 2-Pin USB-C DSP Cable, Storage Pouch, Silicone Eartips (S, M, L), User Manual, QC Pass Card |
