Product Description

PnP version comes pre-mounted into a custom-designed 2M headshell. The headshell is a standard SME-type mount.

The 2M Series of cartridges is designed for precise and accurate retrieval of the information in the record groove. Our philosophy is to play the record sound as accurate as possible, without coloring the sound

The name 2M was selected from several ideas. We wanted a modern name that would be easy to pronounce and remember, and therefore an alphanumerical name was chosen. 2M means MM, which is the abbreviation for moving magnet.

The 2M series of cartridges features Ortofons trademark split pole pins, an invention that enables moving magnet cartridges to have a flat frequency response, as with a moving coil cartridge. Split pole pins were invented by Ortofon, and were originally presented in the 500 series and Super OM series.

We have optimized the design for ease of mounting the cartridge, and the weight and size to fit the most common turntables on the market today. The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps.

The 2M Blue Series features:
2m blue verso
- an improved engine, which provides an increased output of 5.5mV
- Nude Elliptical diamond and split pole pins with a copper wire

2M Headshell features:

  • Universal mount fitting a wide range of tonearms. NB: on Technics models please use the auxiliary weight which is vital in this case.
  • The headshell body is manufactured from a special compound used for Medical industry, ensures high rigidity while reducing unwanted vibration
  • Elegant hi-tech design
  • Length 52mm. Headshell with a 2M cartridge pre-mounted provides correct Baerwald alignment with Ortofon TA-110/210, likewise with the major part of tonearms with universal mount
  • Weight 16,9g, weight with a 2M cartridge pre-mounted 23g
  • Exclusive plug-and-play solution

Technical data

Technical data 2M Blue / 2M Blue Verso
Output voltage at 1000 Hz, 5cm/sec. 5,5 mV
Channel balance at 1 kHz 1,5 dB
Channel separation at 1 kHz 25 dB
Channel separation at 15 kHz 15 dB
Frequency range at - 3dB 20-25.000 Hz
Frequency response 20-20.000 Hz + 2 / - 1 dB
Tracking ability at 315Hz at recommended tracking force 80 µm
Compliance, dynamic, lateral 20 µm/mN
Stylus type Nude Elliptical
Stylus tip radius r/R 8/18 µm
Tracking force range 1,6-2,0g (16-20 mN)
Tracking force, recommended 1,8 g (18 mN)
Tracking angle 20°
Internal impedance, DC resistance 1,3 kOhm
Internal inductance 700 mH
Recommended load resistance 47 kOhm
Recommended load capacitance 150-300 pF
Cartridge colour, body/stylus Black/Blue
Cartridge weight 7,2 g
Replacement stylus unit 2M Blue (interchangeable with2M Red)
Stylus protection guard 2M Blue
How to replace M2,0 mm screws on 2M Blue Verso
Remove the stylus with the stylus protection guard from the cartridge body to avoid any damage to the diamondUsing Torx 8 key, unscrew the black screw from the Verso top plateRemove the top plate from the cartridge body by pulling the screws offRemove the two countersunk screws from the top plateInsert the two M2,0 mm screws in the top plateMount the top plate on the cartridge body. Hold the top plate with screw-threads hanging down and turn the cartridge body 180 degrees. Mount from aboveMount the black screw in the top plate and tighten with appropriate forceMount the cartridge on the tonearm using the enclosed toolMount the stylus with the stylus protection guard on the cartridge body

Manufacturer site

Read More

Specifications

Product Type
Turntable Cartridge
EAN
5705796080025
Cartridge Type
Moving Magnet
GTIN
5705796080025
Stylus
Nude Elliptical
Brand
Ortofon
Condition
New
Product Code
ORTO-2MBLUE-CART
