Oyaide P-004 UL Plug
Platinum/palladium plated

We designed the M1/F1 as our flagship model, making no compromise. The result is a sound that is powerful, dynamic and highly sophisticated. The M1/F1 represents a major step forward in cutting edge technology having inherited and improved upon the advanced technologies of our P series.

Based on the technology of M1/F1, we have achieved to create P-004 as its cost-performance by integrating the features of M1/F1 and P series. As well as other P series audio plugs, the core of P-004 is composed of the selection of materials, plating technology, and usability.

Inheriting the most core factor of M1/F1, the contacts of P-004 are made of beryllium copper which ensures mechanical integrity and high conductivity. The plating is also same as M1/F1 that is a combination of platinum and palladium which was selected after repeated listening tests.

The body is made of 30% glass filled PBT which has excellent machine-ability and provides superior electrical isolation. And the outer cover of P series is made of PC(PolyCarbonate) for its rigidity and hardness. In addition, its “Black-Diamond” color of P-004 outer cover represents its emotional and exciting sound.

Specification:

• Blade: Beryllium copper
• Plating: Platinum (0.5 micron) + Palladium(0.3 micron)
• Install cable O.D.
• min 6.5mm　 max 17.0mm
• Maximum wire gauge
• AWG10(5.5sq)
• Rated V/A
• P-004 : 125V・15A　<PS>E
