IMAX® Enhanced means movies, concerts, and streaming games are delivered with heart-pounding sound and crisp visual enhancements to bring the world into your home theater, just as the filmmakers and sound editors intended. Featuring two HDMI-out options and 100-watts of continuous power per channel, the VSX-LX 305 AV receiver delivers uncompressed HDMI 8K/4K transfer at 40 Gbps, increasing the bandwidth over its predecessors and maximising Next-Gen Gaming features.
Stream songs throughout your home and watch whatever you want in multiple rooms in up to 8K HD. The Pioneer VSX-LX305 is truly next level.
Designed for optimum IMAX® Enhanced and Dolby Atmos®/DTS:X movie playback in a seamless 7.2.2ch/5.2.4ch surround sound calibrated by Advanced MCACC, along with support for next-generation video/gaming standards including HDMI 2.1*1 with 8K, VRR, ALLM, QFT pass-through, the VSX-LX305 brings multi-dimensional excitement to your home entertainment. Dolby Atmos Height Virtualiser provides virtual sound effects without using height or surround speakers. And its Roon Tested so music streaming from AV equipment is super easy. Enjoy multi-room audio streaming with Sonos system, Chromecast built-in, DTS Play-Fi®, and Apple AirPlay 2. It also works with Alexa or Google Assist for voice control.
HDMI 2.1 for a powerful viewing and gaming experience
The VSX-LX305 ensures its HDMI terminals*1 support 8K/60p (4:4:4/12-bit*2, 4:2:0/10-bit*3), 8K/30p (4:4:4/12-bit*2, 4:4:4/10-bit*3, 4:2:2/12-bit*3, 4:2:0/12- bit), 4K/120p (4:4:4/12-bit*2, 4:4:4/10-bit*3, 4:2:2/12- bit*3, 4:2:0/12-bit) video passthrough to compatible displays, as well as HDCP 2.3 so you will have no problem when upgrading to new devices. HDMI 2.1 also supports VRR (Variable Refresh Rate) to eliminate lag, stutter and frame-tearing to deliver a fluid gaming experience. Various enhancements such as ALLM (Auto Low Latency Mode) and QFT (Quick Frame Transport) help to optimise latency and further limit lag to ensure youll always be on top of your game. *1 HDMI 2.1 specification, HDR10+, and passthrough capabilities described are supported on HDMI IN 16, HDMI OUT MAIN and SUB/ZONE 2 in sub mode output. *2 DSC signals only. *3 DSC signals only when input via HDMI IN 4-6. *4 All HDMI terminals support HDCP 2.3.
* 1 HDMI 2.1 specification, HDR10+, and passthrough capabilities described are supported on HDMI IN 16, HDMI OUT MAIN and SUB/ZONE 2 in sub mode output. *2 DSC signals only. *3 DSC signals only when input via HDMI IN 4-6. *4 All HDMI terminals support HDCP 2.3.
IMAX Enhanced
The VSX-LX305 is IMAX Enhanced, certified to deliver the dynamic and heart-pounding sound presented by DTS just as intended by the filmmaker, and provide an immersive experience on your home theater.
Dolby Atmos/Dolby Surround Upmixing
The VSX-LX305 is compatible with 7.2.2ch/5.2.4ch configuration of the latest theater sound platform, Dolby Atmos®. You can reproduce object-oriented sound in smooth, curving movements, or the realistic three-dimensional movement overhead by the top speakers. Other audio codecs such as PCM and DSD can be upmixed using Dolby Surround for enjoying 3D surround sound.
DTX:X/DTS Neural: X Upmixing
DTS:X is the next-generation audio codec from DTS that leverages object-based audio to enable new immersive and interactive audio experiences. Enjoy a seamless soundscape with 7.2.2ch/5.2.4ch surround system offering maximum excitement. Other audio codecs such as PCM and DSD can be upmixed using DTS Neural:X for enjoying 3D surround sound.
Dolby Atmos Height Virtualisation
When playing any Dolby format, engaging the Dolby Atmos Height Virtualiser enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.
Apple AirPlay 2
Apple AirPlay 2 lets you effortlessly stream music or podcasts to speakers throughout your house using any Apple device or by asking Siri, and it all stays in perfect sync.
Advanced MCACC Auto room tuning featuring auto phase control plus
Advanced MCACC adjusts the sound according to the listening room and speakers, and also creates clearer sound by suppressing the standing waves that occur between walls or ceiling and floor. Measurement of up to nine positions can be saved for a wide listening area. Auto Phase Control Plus* makes real-time analysis of the phase difference, and automatically compensates the gap between the LFE and main signals, providing strong bass and clear high-frequency sound.
* Effectiveness depends on content.
Works with SONOS
By bringing the VSX-LX305 into the Sonos eco-system with Connect or Port, you can play any music or audio source on your Sonos app. With Volume Pass Through mode selected at the Sonos App settings, youll be able to control the volume of the unit by Sonos app or by itself. Enjoy high-quality playback from the AV receiver by Sonos app, just as you would with your favorite Sonos system. *Connection of maximum 3 Sonos devices is supported.
Powered Zone 2 with dedicated DAC
With the powered feature, the VSX-LX305 can directly drive speakers in another room, without the need for a separate amplifier. Whats more, the dedicated DAC for Zone 2 lets you listen to all digital audio sources.
Zone B output for wireless headphones
The VSX-LX305 is equipped with Zone B audio output terminals for expanding the Main Zone sound. You can listen to the sound playing in the living room via wireless headphones.
Voice control
The VSX-LX305 works with Hey Google, so you can control playback of various music services supported by Chromecast by asking a Google Assistant enabled device to play, stop, skip, or take the volume up or down. This receiver also works with Alexa, so you can also use voice commands to control supported music services in mulutiple rooms* via Alexa built-in device. Thanks to both voice controls, you can easily operate and enjoy music services or Internet radio with your voice, without using a remote control or smartphone app. *Alexa multi-room music may require a firmware update.
High quality audio transmission by Bluetooth wireless technology
The VSX-LX305 features built-in Bluetooth®receiver and transmitter. Thus not only can you listen to the sound transmitted from your smartphone or tablet with the AV receiver, but you can also listen to the sound input to the AV receiver from Bluetooth® headphones. Supporting aptX and aptX HD codecs for audio transmission, you can enjoy high-quality sound with low latency with compatible headphones.
FM & DAB Radio is also included in the European Model.
Go beyond an experience confined to one room the Pioneer VSX-LX505 AV receiver brings cinema-quality sound and images to multiple rooms for real home entertainment.
SUPPORTED STREAMING SERVICES
Roon Ready, Chromecast built-in, AirPlay 2, Works with Alexa, Spotify Connect, Amazon Music, Tidal, Deezer, TuneIn, DTS Play-Fi, Works with Sonos Supported
ROOM CORRECTION DSP
Dirac Live + MCACC Advanced
SURROUND SOUND TECHNOLOGIES
Dolby Atmos, Dolby Surround, DTS:X, Neural:X, IMAX Enhanced Supported
MEDIA CONNECTION OPTIONS
USB
NETWORK CONNECTIVITY
Wi-Fi & Ethernet
CONTROL INTERFACE
RS232C
AMPLIFIER TYPE
AV Receiver
AVR CHANNELS
9.2
AMPLIFIER CLASS
Direct Energy
POWER OUTPUT (8, 2 CHANNELS DRIVEN)
100 W
PHONO INPUT
MM Input
RCA LINE INPUT(S)
4
BLUETOOTH VERSION
Transmitter / Receiver Connections
HDMI INPUT(S) / OUTPUT(S)
7 In (4 Assignable) / 2 Out (1 eARC)
HDMI SUPPORT
8K (Inputs 1-6) / 4K Ultra HD / HDMI 2.1 / HDCP 2.3 / Dolby Vision / HDR10+
OPTICAL INPUT(S)
1
COAXIAL INPUT(S)
1
FILE LIMIT SUPPORT (PCM)
24-bit, 192kHz
FILE LIMIT SUPPORT (DSD)
DSD256
HEADPHONE OUTPUT
6.3mm Jack
SUBWOOFER OUTPUT(S)
2 (single RCA)
ZONE 2 OUTPUTS
Stereo RCA / HDMI
TRIGGER CONNECTION
Y
APP CONTROL
Pioneer Remote
DIMENSIONS (W X H X D)
435 x 173 x 370.5 mm
WEIGHT
10.4 kg
